High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Nombre De La Marca:	SENCAN
Número De Modelo:	SC-TP-814
Cantidad Mínima De Pedido:	1 juego
Precio:	Negotiate price according to actual situation
Condiciones De Pago:	T/T, L/C
Capacidad De Suministro:	2-20 juegos

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Porcelana

Certificación:

CE, ISO9001

Medidor de presión de aire:

SMC

Velocidad de funcionamiento:

Ajustable

Método operativo:

Discos giratorios/mecánicos

Ratio de eficiencia:

Por encima del 95%

Persona de la operación:

1 persona

Material:

Acero inoxidable

Potencia de producto:

220V

Frecuencia:

50/60Hz

Capacidad de ensamblaje:

4500-12000 por hora

Operador:

Soltero

Tasa satisfactoria:

Alrededor del 99%

Tapas aplicables:

Las capitalizaciones en euros

Modo de operación:

Semiautomático

Mecanismo:

Servo

Detalles de empaquetado:

Caja de madera

Resaltar:

Fast and Accurate Euro Cap Assembly Machine

99% Satisfactory Rate Infusion Cap Assembly Machine

4500-12000 per/hour Automatic Cap Assembly Machine

Descripción del producto

High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly

Product Features

Designed for automatic assembly of easy peel foil caps for IV infusion soft bags and bottles
Constructed with stainless steel and aluminum alloy materials, compliant with GMP standards
Independent driving source for each workstation, facilitating easy maintenance
Product-contact surfaces polished for optimal product protection
Automated foil cutting and welding process
Integrated check function after each assembly step to ensure product quality
PLC control system with user-friendly interface, requiring minimal operator training
Servo motor + indexing drive power system for high precision assembly and qualification rates
Pneumatic power system reduces maintenance time and technical requirements
Fully customizable to meet specific product specifications, capacity, and production demands

Technical Specifications

Applicable Products	Peel seal foil caps, foil seal closures and lids
Production Speed	1500-8500pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kw/hr
Dimensions	Varies according to production speed requirements
Weight	Approximately 2000kg
Operator Requirements	3 sets/2 persons, recommended 1 set/person
